VGA to HDMI Converter


Categories:
> VGA/Video Convertors, DVI Digital Electronics
VGA to HDMI Converter


Transcode analog video to digital video with this professional-grade VGA converter box. With digital output in DVI or HDMI formats (including HDTV resolutions), plus stereo and optical audio passthrough, this video adapter is the highest-quality solution to an analog/digital video mismatch.

MDV-104A   VGA to DVI-D/HDMI Converter   EACH $ 299.00   1 in stock   Add to Cart

Designed for running an analog VGA video source to a digital DVI/HDMI display, the MDV-104A is the highest quality video converter we've ever carried. It uses per-pixel mapping for perfectly crisp and clear images, and supports all HDTV resolutions up to 1080p as well as computer displays up to 1920x1200.

There are many challenges in converting an analog source to a digital display, as our dozens of phone calls and emailed questions will testify. The short answer is that it's hard to do it cheap, and even harder to do it well. At DataPro we believe it doing it well, and that's why we choose to carry this particular VGA-HDMI adaptor.

The MDV-104A features display detection and native resolution support, and can also be manually configured. Control buttons allow adjustment of resolution, brightness, contrast, hue, sharpness, and RGB levels through an on-screen menu.

Additionally, this video box features a 3.5mm stereo audio input, for high-fidelity sound to match the high-definition video. The audio signals received on the input port is injected into the HDMI output for combined audio/video.

The unit is powered by an external 12V DC supply (included) and requires no drivers or software. It is transparent to the operating system and displays involved.


Features:

  • Converts and scales VGA and L/R analog audio to HDMI
  • No drivers or software required
  • Supports HDTV resolutions up to 1080p
  • Supports computer resolutions up to 1920x1200 (WUXGA)
  • Combines input audio and video into HDMI
  • On-screen display (OSD) menu allows easy set-up and control
  • Test Pattern Generator for quick system configuration
  • Aspect Ratio Control: Full Screen, Panoramic, Letter/Pillar, Extract/Crop


Specifications:

  • Input ports: 1 x VGA, 1 x 3.5mm Audio Jack
  • Output ports: 1 x HDMI
  • Power Supply: 12V DC
  • Operating Temperature: Operating from 32-122F (0-50C)
  • Dimensions: 4.9" x 1" x 3.2" (123mm x 26mm x 82mm)
  • Weight: 0.4lbs (0.2kg)
