Shielded Cat6 Panel Mount Extension

Technical Documents

The DataPro shielded Cat6 panel mount RJ45 cable is the perfect way to extend a shielded 250 MHz, Cat6, RJ45 connection to any plate, panel, or bulkhead. Requires no termination or punch-downs, and includes panel mounting hardware. This secure mount is sized for installation on our face plates without any on-site termination.

See below for drawing and cutout size.

Please note that custom-built lengths of this cable may vary in appearance. If you have specific aesthetic requirements, please contact us.

Click here for PDF version

Features:

• Mount and extend a shielded Cat6 RJ45 Ethernet connection
• Bulkhead-mountable shielded RJ45 jack
• Rugged molded PVC hood

Specifications:

• 1x RJ45, Cat6, shielded panel-mount Female connector
• 1x RJ45, Cat6, Male connector
• Jacket: PVC
• Wire Gauge 26 AWG
• Frequency: 250 MHz
• Embedded 4-40 nuts with mounting screws included
• Compatible with 10-Base-T, 100-Base-T, 1000-Base-T Gigabit, and 10-Gigabit networks
• Backwards-compatible with Cat-5 and Cat-5e
