14-Pin VGA Legacy Cable M-M


Categories:
> VGA Cables 		14-Pin VGA Legacy Cable M-M


1055-03C   SVGA Video Cable M-M, No Pin 9   3 ft $ 10.95   41 in stock   Add to Cart
1055-06C   SVGA Video Cable M-M, No Pin 9   6 ft $ 12.95   302 in stock   Add to Cart
1055-10C   SVGA Video Cable M-M, No Pin 9   10 ft $ 21.95   31 in stock   Add to Cart
1055-15C   SVGA Video Cable M-M, No Pin 9   15 ft $ 32.95   205 in stock   Add to Cart
1055-25C   SVGA Video Cable M-M, No Pin 9   25 ft $ 42.00   81 in stock   Add to Cart
1055-50C   SVGA Video Cable M-M, No Pin 9   50 ft $ 72.00   68 in stock   Add to Cart
1055-75C   SVGA Video Cable M-M, No Pin 9   75 ft $ 82.00   7 in stock   Add to Cart
1055-99C   SVGA Cable Video M-M, No Pin 9   100 ft $ 122.00   10 in stock   Add to Cart
1055-00C   SVGA Video Cable M-M, No Pin 9
Custom build at $95.43 + $1.50 per foot.
Some custom products may not be REACH compliant.		   Add to Cart

This cable is identical to our 1155 VGA Cable, but is missing Pin 9. This is necessary for compatibility with some types of older hardware.

All of our VGA cables are built using triple-shielded mini-coaxial wire, so the Red, Green, and Blue signals are individually insulated and shielded. The signal wires are 75 Ohm 28 AWG coax, which is the ideal spec for video and allows us to build cables in excess of 200 feet long.

Drawings & Models:

PartDownloads
1055PDF Drawing (PDF)STEP Model (STEP)


RoHS Compliant
REACH Compliant
IPC Compliant
Related Products:

Features:

  • Gold-plated contacts
  • Low-loss cable allows lengths of up to 200 feet in most cases, with good strength and fidelity.

    Specifications:

    • 2x Male DH15 VGA Connectors, No Pin #9
    • Wire Gauge 28 AWG or 28 & 24 AWG
    • RoHS Compliant
    • CL2 Rated
    • Made of 75 Ohm video-grade coaxial wire
    • Triple-shielded mini-coax wire
    • 2x ferrite cores
